01 · Product overview
The DWSCNC DT52-550CY extends the turning length and workpiece envelope for buyers machining medium shaft or disk components. It is suited to factories that need flexible turning and milling in a single machine platform.
02 Key advantages
- Longer turning length than compact CY models
- Interpolated Y-axis for secondary machining
- Side or rear chip conveyor options
- Balanced choice for mixed part production
03 Technical specifications
| Turning diameter | 330 mm disk type / 330 mm shaft type |
|---|---|
| Turning length | 563 mm |
| Bed structure | Integrated 15-degree step bed with 30-degree interpolated Y-axis |
| Spindle nose | A2-6 / A2-8 options |
| Chip conveyor | Side mounted / rear mounted options |
